Modulus Arms SpeedMILL™
Please Note: The Modulus Arms Router Jig Extreme™ requires the use of one of our SpeedMill™ end mills.
The Modulus Arms SpeedMILL™ harnesses the power of a handheld router to produce an exceptionally smooth finish with no prior experience required. The SpeedMILL™ utilizes a thermal fit tool coupler which attaches directly to your router. This prevents the end mill from coming loose from the collet during milling, which is a common issue with other types of jigs.
The steel coupler portion of the 80% lower jig tool is heated, causing it to expand and accept a 5/16" diameter solid carbide end mill, which is specifically designed for router based 80% lower milling. The end mill is thermal fit into the tool holder so it will not slip out during use. The end mill portion of the SpeedMILL™ can be replaced by the customer by heating the steel coupler with a torch.
The length of the carbide end mill portion of the SpeedMILL™ has been reduced to just 1.5 inches. This is under half the length of any other type of end mills designed for router based milling in an 80% lower jig. This reduced length results in an ultra-rigid milling tool that produces a mirror finish in record setting time.
Check this table to find the correct SpeedMill™ version to fit your router.
|ROUTER ||SpeedMill™ SELECTION |
|BOSCH PR10E ||SpeedMill #V1 |
|BOSCH PR20EV ||SpeedMill #V1 |
|DEWALT DWE6000 ||SpeedMill #V1 |
|PORTER CABLE 6430 ||SpeedMill #V1 |
|PORTER CABLE 6435 ||SpeedMill #V1 |
|RIGID R24012 ||SpeedMill #V1 |
| || |
|CRAFTSMAN 28212 ||SpeedMill #V2 |
|DEWALT DWP611 ||SpeedMill #V2 |
|PORTER CABLE 450 ||SpeedMill #V2 |
| || |
|MAKITA RT0701C ||SpeedMill #V3 |
| || |
|THESE ALL REQUIRE THE ADDITIONAL FULL-SIZE ROUTER PLATE || |
|BOSCH 1617EV ||SpeedMill #V4 |
|BOSCH 1617EVS ||SpeedMill #V4 |
|CRAFTSMAN 2767 ||SpeedMill #V4 |
|CRAFTSMAN 27683 ||SpeedMill #V4 |
|CRAFTSMAN 50429 ||SpeedMill #V4 |
|DEWALT DW616 ||SpeedMill #V4 |
|DEWALT DW618 ||SpeedMill #V4 |
|HITACHI M12VC ||SpeedMill #V4 |
If you have a router not listed, you can reference the below sizing and thread pitch, and see which would match up with your routers spindle. It can be tricky to get these measurements, and for more information on collecting the info, you can visit:
|Spindle Diameter ||Tool Size ||Thread & Pitch |
|0.55” / 13.9 mm ||1 ||M14 x 1 |
|0.59” / 15 mm ||2 ||M15 x 1 |
|0.66” / 16.8 mm ||3 ||M17 x 1 |
|0.78” / 19.9 mm ||4 ||M20 x 1 |
